EDGE, SIDE PLATE - WA480

Wide range of available as Japanese high quality products

Equipment : Wheel Loader
KMVL P/N :
LH : WL-KOM-BLL301-SPL
　Thickness : 25mm
　Width : 254mm
　Length : 513mm
　Bolt Size : 7/8-in Plow bolt
　Bolt Hole : 2H
　*Boron steel - HB500
RH : WL-KOM-BLL301-SPR
　Thickness : 25mm
　Width : 254mm
　Length : 513mm
　Bolt Size : 7/8-in Plow bolt
　Bolt Hole : 2H
　*Boron steel - HB500
Model :
[KOMATSU]
WA300 / WA320 / WA350 / WA380 / WA400 / WA430 / WA450 / WA470 / WA480
Parts number :
・WL-KOM-BLL301-SPL : 421-70-22990
・WL-KOM-BLL301-SPR : 421-70-22980
Weight :
・WL-KOM-BLL301-SPL : 14.3 KGS
・WL-KOM-BLL301-SPR : 14.3 KGS

Remarks :

We will propose and provide the best way for the machine. Also, we are possible to provide our products as OEM, ODM and private brand.
If you have any questions, please do not hesitate to contact us!
