CUTTING EDGE, CURVED - L=1524mm

Wide range of available as Japanese high quality products

Equipment : Motor Grader
KMVL P/N :
01) GD-ALL-BLM1307-5/8-CE
　Thickness : 13mm
　Width : 152mm
　Length : 1524mm
　Bolt Size : 5/8-in Plow bolt
　Bolt Hole : 7H
　*Boron steel - HB500
02) GD-ALL-BLM1311-5/8-CE
　Thickness : 13mm
　Width : 152mm
　Length : 1524mm
　Bolt Size : 5/8-in Plow bolt
　Bolt Hole : 11H
　*Boron steel - HB500
03)GD-ALL-BLM1311W-5/8-CE
　Thickness : 13mm
　Width : 203mm
　Length : 1524mm
　Bolt Size : 5/8-in Plow bolt
　Bolt Hole : 11H
　*Boron steel - HB500
04)GD-ALL-BLM1607-5/8-CE
　Thickness : 16mm
　Width : 152mm
　Length : 1524mm
　Bolt Size : 5/8-in Plow bolt
　Bolt Hole : 7H
　*Boron steel - HB500
05)GD-ALL-BLM1611-5/8-CE
　Thickness : 16mm
　Width : 152mm
　Length : 1524mm
　Bolt Size : 5/8-in Plow bolt
　Bolt Hole : 11H
　*Boron steel - HB500
06)GD-ALL-BLM1611W-5/8-CE
　Thickness : 16mm
　Width : 203mm
　Length : 1524mm
　Bolt Size : 5/8-in Plow bolt
　Bolt Hole : 11H
　*Boron steel - HB500
Model :
・GD-ALL-BLM1307-5/8-CE
[KOMATSU]
GD28AC / GD30 / GD31 / GD300A / GD305A / GD355A / GD405A
[CAT/MITSUBISHI]
MG200 / MG230 / MG300 / MG330
・GD-ALL-BLM1311-5/8-CE
[KOMATSU]
GD28AC / GD30 / GD31 / GD300A / GD305A / GD355A / GD405A
[CAT/MITSUBISHI]
MG200 / MG230 / MG300 / MG330
・GD-ALL-BLM1311W-5/8-CE
[KOMATSU]
GD28AC / GD30 / GD31 / GD300A / GD305A / GD355A / GD405A
[CAT/MITSUBISHI]
MG200 / MG230 / MG300 / MG330
・GD-ALL-BLM1607-5/8-CE
[KOMATSU]
GD28AC / GD30 / GD31 / GD300A / GD305A / GD355A / GD405A
[CAT/MITSUBISHI]
MG200 / MG230 / MG300 / MG330
・GD-ALL-BLM1611-5/8-CE
[KOMATSU]
GD28AC / GD30 / GD31 / GD300A / GD305A / GD355A / GD405A
[CAT/MITSUBISHI]
MG200 / MG230 / MG300 / MG330
・GD-ALL-BLM1611W-5/8-CE
[KOMATSU]
GD28AC / GD30 / GD31 / GD300A / GD305A / GD355A / GD405A
[CAT/MITSUBISHI]
MG200 / MG230 / MG300 / MG330
Parts number :
・GD-ALL-BLM1307-5/8-CE
[KOMATSU]
233-70-12141-7H[CAT/MITSUBISHI]
61381-00300 / 62681-04300 / 61381-10300
・GD-ALL-BLM1311-5/8-CE
[KOMATSU]
233-70-12141-11H[CAT/MITSUBISHI]
9J3862
・GD-ALL-BLM1311W-5/8-CE
[KOMATSU
233-70-12141W-11H[CAT/MITSUBISHI]

・GD-ALL-BLM1607-5/8-CE
[KOMATSU]
238-70-12220-7H[CAT/MITSUBISHI]
7T1640 / 63681-12200
・GD-ALL-BLM1611-5/8-CE
[KOMATSU]
238-70-12220-11H[CAT/MITSUBISHI]
7D4508
・GD-ALL-BLM1611W-5/8-CE
[KOMATSU]
238-70-12220W-11H[CAT/MITSUBISHI]
7D4509
Weight :
・GD-ALL-BLM1307-5/8-CE : 20.7 KGS
・GD-ALL-BLM1311-5/8-CE : 20.7 KGS
・GD-ALL-BLM1311W-5/8-CE : 29 KGS
・GD-ALL-BLM1607-5/8-CE : 24.2 KGS
・GD-ALL-BLM1611-5/8-CE : 24.2 KGS
・GD-ALL-BLM1611W-5/8-CE : 35 KGS

Remarks :

We will propose and provide the best way for the machine. Also, we are possible to provide our products as OEM, ODM and private brand.
If you have any questions, please do not hesitate to contact us!
