WELD-ON ADAPTERS - KOMATSU / 6.0 tons ~

Wide range of available as Japanese high quality products

Equipment : Excavator
KMVL P/N - SIZE :
CENTER [H] : KOM078-AD-WD-22C-SI
> LT : 22mm / Beveled
CENTER [H] : KOM078-AD-WD-22S-SI
> LT : 22mm / Non-Beveled
CENTER [H] : KOM078-AD-WD-25S-SI
> LT : 25mm / Non-Beveled
CENTER [V] : KOM078-AD-WD-25S-VC
> LT : 25mm / Non-Beveled
[H] : Horizontal type / [V] Vertical type
Manufacturer : Komatsu
Model :
PC60/PC78US/PC78UU
Please check the actual machines for size and specifications of GET in advance.
The above models are for reference.
Parts number :
KOM078-AD-WD-22C-SI : 20X-70-14151
KOM078-AD-WD-22S-SI : 20X-70-14151-22
KOM078-AD-WD-25S-SI : 20X-70-14151-25
KOM078-AD-WD-25S-VC : 20X-70-23150
Weight :
KOM078-AD-WD-22C-SI : 3.15 KGS
KOM078-AD-WD-22S-SI : 3.1 KGS
KOM078-AD-WD-25S-SI : 3 KGS
KOM078-AD-WD-25S-VC : 5.4 KGS

Remarks :


We will propose and provide the best way for the machine. Also, we are possible to provide our products as OEM, ODM and private brand.
If you have any questions, please do not hesitate to contact us!
