KUKKO - 3-jaw Pullers / Extra Powerful

Wide range of available as Japanese high quality products

Equipment : KUKKO - 3-jaw Pullers / Extra Powerful
KMVL P/N & Description : Below

Parts number	External Pulling Capacity (mm)	Internal Pulling Capacity (mm)	Arm Length (mm)	Maximum Load (t)
11-0-A	105-375	220-500	200	15
11-0-A3	105-375	220-500	300	15
11-0-A4	105-375	220-500	400	15
11-0-A5	105-375	220-500	500	15
11-1-A	125-520	280-600	200	20
11-1-A3	125-520	280-600		20
11-1-A4	125-520	280-600	400	20
11-1-A5	125-520	280-600	500	20
11-2-A	155-650	290-740	200	20
11-2-A3	155-650	290-740	300	20
11-2-A4	155-650	290-740	400	20
11-2-A5	155-650	290-740	500	20

Description :
The extra sturdy 3-jaw universal puller is used for removing heavy bearings, gears, and discs in all common sizes. This allows loosening any component that sits on a shaft and is freely accessible from the outside. The robust jaws ensure a safe disassembly.

Advantage :
• Screw connection allows easy loosening and particularly tight fastening of the jaws with an allen key.
• 3-jaw ensures an even distribution of force and allows for greater pulling forces.
• Application also for eccentric components through freely movable, sliding puller jaws on the crossbar.
• Variable adjustment to any spread between 105 mm - 650 mm.
• Secure attachment of the spindle through a rotatable spindle tip on both smooth surfaces and during centering (Switch Technology)
• Safe mounting of the spindle with a movable spindle tip on both smooth surfaces and for centering (Switch Technology).
