KUKKO - Narrow Jaws for replacement

Wide range of available as Japanese high quality products

Equipment : KUKKO - Narrow Jaws for replacement
KMVL P/N & Description : Below

Parts number	Jaw Length (mm)	Jaw Width (mm)	A (mm)	B (mm)	C (mm)	D (mm)	E (mm)	Suitable for
1-91-P	100	127	3	30	7	14	3	20-1-S,20-10-S
1-191-P	200	227	3	30	7	14	3	20-1-S,20-10-S
1-251-P	250	277	3	30	7	14	3	20-1-S,20-10-S
1-401-P	400	427	3	30	7	14	3	20-1-S,20-10-S
2-151-P	150	186	4	32	8	19	4	20-2-S,20-20-S
2-301-P	300	336	4	32	8	19	4	20-2-S,20-20-S
3-201-P	200	244	6.5	35	17	52	6.5	20-3-S,20-30-S
3-301-P	300	340	6.5	35	17	52	6.5	20-3-S,20-30-S
3-401-P	400	440	6.5	35	17	52	6.5	20-3-S,20-30-S
3-501-P	500	540	6.5	35	17	52	6.5	20-3-S,20-30-S
1-91-S	100	127	3	30	7	14	3	30-1-S, 30-10-S
1-191-S	200	227	3	30	7	14	3	30-1-S, 30-10-S
1-251-S	250	277	3	30	7	14	3	30-1-S, 30-10-S
1-401-S	400	427	3	30	7	14	3	30-1-S, 30-10-S
2-151-S	150	186	4	32	8	19	4	30-2-S,30-20-S
2-301-S	300	336	4	32	8	19	4	30-2-S,30-20-S
3-201-S	200	244	6.5	35	17	52	6.5	30-3-S
3-301-S	300	340	6.5	35	17	52	6.5	30-3-S
3-401-S	400	440	6.5	35	17	52	6.5	30-3-S
3-501-S	500	540	6.5	35	17	52	6.5	30-3-S

* -P = For 2-jaws (2 jaws are included per 1pc)
* -S = For 3-jaws (3 jaws are included per 1pc)

Description :
The narrow jaws ensure that even tight and hard-to-reach spaces can be accessed.

Advantage :
・Through the freely movable, gliding jaws on the crossbar, even eccentric components can be removed.
