TRACK SHOE, TRIPLE - KOMTASU EX-MINI 4.0 tons ~ / P135

Wide range of available as Japanese high quality products

Equipment : Excavator
KMVL P/N :
350mm : EX-KOM-TS135/011-350T
400mm : EX-KOM-TS135/011-400T
Manufacturer : Komatsu
Model :
350mm : PC40MR-3
400mm : PC40-7/PC40MR-1.2.3/PC40R-7.8/PC45MR-5/PC50UU-2/PC50MR-2/PC55MR-3.5/PC58UU-3.5/BR100JG-2
Parts number :
350mm : 22M-32-37220
400mm : 20T-32-77410
Weight :
350mm : 3.62 KGS
400mm : 4.17 KGS

Remarks :
Length : 350mm / 400mm
LINK PITCH : 135mm
Thickness : 6mm
MUD hole : YES
Bolt hole : φ12.2
Pad hole : YES
Berco :
USCO :
ITM :

We will propose and provide the best way for the machine. Also, we are possible to provide our products as OEM, ODM and private brand.
If you have any questions, please do not hesitate to contact us!
