TRACK SHOE, TRIPLE [NEW] - KOMATSU EX-XL 40.0 tons~ / P228.6

Wide range of available as Japanese high quality products

Equipment : Excavator / Others
KMVL P/N :
600mm : EX-KOM-TS228/011-600T
700mm : EX-KOM-TS228/011-700T
800mm : EX-KOM-TS228/011-800T
Manufacturer : Komatsu
Model :
[Excavator]
PC400-6.7.8.10/PC450-6.7.8.10
[Others]
BR500JG-1
Parts number :
600mm : 208-32-61110
700mm : 208-32-61310
800mm : 208-32-61320
Weight :
600mm : 25.19 KGS
700mm : 29.54 KGS
800mm : 33.9 KGS

Remarks :
Length : 600mm / 700mm / 800mm
LINK PITCH : 228.6mm
Thickness : 13mm
MUD hole : YES
Bolt hole : φ24.3
Pad hole : NO
Berco :
USCO :
ITM :
600mm : Z40403G0N0600V
700mm : Z40403G0N0700V
800mm : Z40403G0N0800V

We will propose and provide the best way for the machine. Also, we are possible to provide our products as OEM, ODM and private brand.
If you have any questions, please do not hesitate to contact us!
